Ulefone Armor Mini 20 4G Specifications
|
Physical Characteristics
|
Color
|
Black
|
Material
|
PC
|
USB
|
Type-C, USB 2.0
|
Headphone Jack
|
3.5mm Headphone Jack
|
Expansion Connector
|
N/A
|
Card Slots
|
2, 1x Nano-SIM + 1x Nano-SIM/microSD
|
Keys
|
Right: Power button(Fingerprint)+Volume button, Left: Custom Key
|
Size & Weight
|
Product Size
|
133.5 x 63.3 x 24.9 mm
|
Product Weight
|
301g/10.6 ounces
|
Package Size
|
99 x 198 x 77.5 mm
|
Product size and weight may vary by configuration, manufacturing process and measurements.All specifications are subject to the actual product.
|
Ruggedness
|
Certification
|
IP68/IP69K/MIL-STD-810H
|
Splash, Water, and Dust Resistant
|
Maximum depth of 20m up to 30 minutes
|
Drop resistance
|
Up to 10m tall
|
Working Temperature
|
-20℃ - 55 ℃ (-22℉ - 131℉)
|
Display
|
Screen Size
|
4.7-inch
|
Screen Resolution
|
720 x 1600 HD+
|
Aspect Ratio
|
20:9
|
PPI
|
373
|
Color Depth
|
8bit, 16.7M
|
Refresh Rate
|
90Hz
|
Screen-to-Body Ratio
|
79%
|
Multi-touch
|
5
|
Processor
|
CPU Model
|
MediaTek Helio G99
|
Main frequency
|
2.2GHz
|
CPU Core
|
2x Arm Cortex-A76 2.2GHz, 6x Arm Cortex-A55 2.0GHz
|
GPU
|
Arm Mali-G57 MC2
|
RAM & Storage
|
RAM
|
16GB =8GB LPDDR4X + 8GB virtual RAM (The virtual RAM can be activated in Settings at your will. )
|
ROM
|
256GB UFS2.2
|
Max. Expansion Supported
|
2TB
|
Rear Camera
|
Rear Camera Numbers
|
2
|
Main Rear Camera
|
Pixel: 50MP
|
Details: Samsung GN1 CMOS sensor, 1.2μm, 7 piece lens, FOV 85°, ƒ/1.95 large aperture
|
Night Vision Camera
|
Pixel: 64MP
|
Details: OV64B1B CMOS sensor, FOV 79.8°, ƒ/1.79 large aperture
|
Flash
|
2
|
Video Recording Resolution
|
2K@30fps, FHD@30fps, HD@30fps, VGA@30fps
|
Special Features
|
Normal mode, Film mode, 50MP mode, Night mode, Document correction, GroupPhoto, AI Emoji, Gif, Portrait, Sports, Pro mode, Panorama, Slow motion, Time lapse, Intelligent acanning
|
Front Camera
|
Pixel
|
32MP
|
Details
|
Details: Samsung GD1 CMOS sensor, 0.8μm, 5 piece lens, FOV 80.4°, ƒ/2.45 large aperture
|
Video Recording Resolution
|
2K(30fps), FHD(30fps), HD(30fps), VGA(30fps)
|
Special Features
|
Normal mode, Film mode, GroupPhoto, AI Emoji, Gif, Portrait
|
Battery & Charging
|
Capacity
|
6200mAh
|
Watt Hours Per Battery
|
23.994 Wh
|
Battery Type
|
Li-ion Sub-zero Solid-State Battery
|
Charging Details
|
33W, 11V3A
|
Wireless Charge
|
Support, 15W, Ulefone private protocol
|
Reverse Charge
|
Wireless Reverse Charging, 5W
|
Standby Time
|
336 Hours
|
Talk Time
|
34 Hours
|
Network & Connectivity
|
Card Type
|
Nano+Nano/microSD
|
Cellular
|
4G/3G/2G
|
Band Details
|
4G/3G/2G
|
4G: FDD-LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/
26/28A/28B/32/66/71
TDD-LTE: B34/38/39/40/41
|
3G: WCDMA: B1/2/4/5/6/8/19
|
2G: GSM: B2/3/5/8 CDMA: BC0/BC1/BC10
|
Standby Mode
|
Dual sim dual standby
|
VoNR
|
Support
|
VoLTE
|
Support
|
WiFi
|
2.4G/5G, 802.11 a/ac/b/g/n
|
Bluetooth Version
|
BT5.2
|
Navigation
|
GPS/GLONASS/Beidou/Galileo/QZSS
|
Audio
|
Speaker Numbers
|
1
|
Speaker Model
|
1326 BOX
|
Speaker Power
|
Max 1.5W
|
Smart PA
|
AW88394
|
Versatile LED Light
|
LED Beads
|
130 Pieces (102 white light beads,14 blue light beads, 14 red light beads)
|
Brightness
|
Max 500 lumens
|
Light Power
|
Max 5W
|
Shortcut Key
|
Support, Custom Key
|
APP
|
Camping Light
|
Modes
|
Lighting, adjustable brightness settings; duration settings of 5-30mins.
|
Sharp Light, duration settings of 5-30mins.
|
SOS
|
Safety Protection
|
Support
|
Warning Light
|
APP
|
RedBluePoliceLight
|
Simulated Light Effect
|
Red Light, Blue Light, Red-Blue Light
|
Simulated Warning Sound
|
Fire, Ambulance, Police Car, and other first responding warning sound
|
Lighting Modes
|
2, Constant or Blink
|
Security
|
Fingerprint ID
|
Support
|
Face Unlock
|
Support
|
System & Features
|
Android Version
|
Android 14
|
Language
|
Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese
|
Blinking Notification Light
|
Support, red/green/blue light
|
Battery Status Light
|
Support
|
Audio Format Supported
|
MID/FLAC/MKA/MP3/M4A/AAC/AMR/OGG/MP2
|
Video Format Supported
|
MOV/MKV/3GP/MP4
|
Image Format Supported
|
GIF/JPEG/PNG/BMP
|
Text Format Supported
|
TXT/HTML
|
FM Radio
|
Support,headset-free FM radio
|
Cell Broadcast
|
Support
|
Sensor
|
Proximity Sensor, Gravity sensor, Light Sensor, Acceleration Sensor, Geomagnetic sensor, Gyro sensor, Coulomb counter, Pedometer, Air pressure sensor, Infrared sensor
|
Special Features
|
Underwater Camera
|
Support
|
Gloves Mode
|
Support
|
Digital Toolbox
|
Height Meter, Compass, Gradienter, Flashlight, Hanging Painting, Magnifier, Alarm bell, Plumb bob, Protractor, Noise Test, Pedometer, Barometer, Funny Sound
|
OTG Function
|
Support Reverse Charging
|
NFC
|
Support
|
IR Blaster
|
Support
|
Others
|
Packing List
|
1 x Phone 1 x AC Power Charger, 33W 1 x Type-C to Type-C Data Cable (100cm) 1 x Protective Film (Pre-installed) 1 x SIM Needle 1 x Lanyard 1 x Multi-language User Manual 1 x Multi Function Instruction Card 1 x Warranty Card 1 x Charging Instruction Card 1 x Safety Prompt Card 1 x Accessories Ecosystem Brochure 1 x Service Center APP Instructions
|
Product Certification
|
CE, IP68, IP69K, MIL-STD-810H, WEEE, ROHS.TAC, UN38.3,MSDS, IEC62133
|
